The price covers the tracker structure and controller. Installation requires a concrete foundation or ground screws and a crane or aerial work platform; flat-roof mounting needs a structural engineer’s assessment.
| Panel size | 1791x1052 mm |
| System weight | ~1930 kg/system |
| Footprint | ~44 m² |
| Installed capacity | ~9 kW |
| Number of panels | 24 pcs |
| Expected lifetime | >25 years |
| Control algorithm | astronomical algorithm + position sensor, closed-loop control |
| Night return mode | yes |
| Anemometer | yes |
| GPS | yes |
| Drive motor protection | yes |
| Storm protection | yes |
| Tracking algorithm | yes |
| Rain cleaning mode | optional |
| Snow cleaning mode | optional |
| Actuation | slew drive + linear actuator |
| Communication | bluetooth, WiFi, 4G |
| Rotation monitoring | sensor and software protection |
Panel size: 1791x1052 mm. Astronomical algorithm with position sensor, closed-loop control, GPS, anemometer and storm protection.
Panel size: 1791x1052 mm. Astronomical algorithm with position sensor, closed-loop control, GPS, anemometer and storm protection.
